Dây chuyền sản xuất ván sợi khoáng sản
Created with Pixso.

Rock Wool Production Line with 1200-2400mm Length and Class A1 Fire Resistance Including Overseas Engineer Support

Rock Wool Production Line with 1200-2400mm Length and Class A1 Fire Resistance Including Overseas Engineer Support

Tên thương hiệu: Greenson
MOQ: 1
giá bán: US $2000000-4000000
Điều khoản thanh toán: L/C, T/T.
Thông tin chi tiết
Nguồn gốc:
HEBEI
Tên sản phẩm:
Dây chuyền sản xuất tấm len đá sản xuất tại Trung Quốc Nhà máy sản xuất máy làm len khoáng sản
Từ khóa:
Nhà máy dây chuyền sản xuất ván len đá
Năng lực sản xuất:
10000-50000TON/năm
Tỉ trọng:
100-200kg/m3
Quá trình chính:
trộn, hình thành, cắt nước, sấy khô
Kháng lửa:
Lớp A1
Chiều dài:
1200-2400mm
Dịch vụ sau bán hàng:
Các kỹ sư có sẵn cho máy móc dịch vụ ở nước ngoài
Làm nổi bật:

1200-2400mm Length Rock Wool Production Line

,

Class A1 Fire Resistance Mineral Wool Board Production Line

,

Overseas Engineer Support Rock Wool Panel Production Line

Mô tả sản phẩm
Made In China Rock Wool Panel Production Line Mineral Wool Making Machine Factory
The raw materials used in rock wool production include basalt, dolomite, binders, etc. The raw materials are loaded into the hopper by the elevator, and the melting furnace is heated and melted into the melt flow tank. The lava flow is cooled and spun into fibers by the centrifuge, and then sprayed into the fiber molding room. The binder is added during the spraying process, and the fibers are heated by the negative pressure wind. Pull down to the mesh belt to form the original felt. The mesh belt transports the original felt to the pendulum cloth machine to swing the cloth. The original felt after the swing cloth is transported to the curing furnace by the cloth machine, and runs forward between the upper and lower chain belts. The hot air blower blows the hot air into the curing furnace. The cotton felt in the furnace is solidified, and the solidified products are cut, first longitudinally cutting, and then transversely cutting, and the finished product is packaged and put into storage.
Product Parameters
Specification Details
Application Manufacture Rock Wool Blanket, Rock Wool Board
Capacity 10000tons/year, 20000tons/year, 30000tons/year, 40000tons/year, 50000tons/year, 60000tons/year, 70000tons/year, 80000tons/year
Raw materials Basalt, dolomite, binders and so on
Main energy supply system
  • Raw coal energy supply system
  • Power energy supply system
  • Natural gas energy supply system
Frequently Asked Questions
Q: Where is the factory located?
A: We are located in Shijiazhuang, Hebei Province.
Q: What is your delivery time?
A: Usually, we make merchandise inventory. If we have the products in stock, the delivery time is 30-60 days after receiving the deposit. If we don't have the products in stock, we will arrange the production immediately, with delivery time of 1-3 months depending on order quantity.
Q: How can we ensure quality?
A: The final inspection is always carried out before shipment.
Q: How to install the equipment after purchasing?
A: Professional designing, manufacturing, installation and commissioning team. On-site installation and commission until the production of qualified products.
Q: Do you offer a guarantee?
A: Yes, we guarantee our product for one year. Provide after-sales service support with technical support.
