Dây chuyền sản xuất ván sợi khoáng sản
Created with Pixso.

Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Tên thương hiệu: Greens
Số mẫu: Máy làm tấm tường len đá
MOQ: 1
giá bán: US $2000000-4000000
Điều khoản thanh toán: L/C, T/T.
Thông tin chi tiết
Nguồn gốc:
HEBEI
Tên sản phẩm:
Máy làm tấm tường bằng đá len cách nhiệt chống cháy
Từ khóa:
Dây chuyền sản xuất đá len xây dựng tường xen kẽ tường cách nhiệt bên trong
Điện áp:
380V hoặc tùy chỉnh
Tốc độ truyền tải:
40 ~ 120 mét/phút
Chiều rộng dây đai xoay:
2800mm
Động cơ dây đai xoay:
4kW (Động cơ tần số biến)
Độ dày của bảng điều khiển:
20-250mm
Mật độ bảng điều khiển:
30-250 kg/m³
Làm nổi bật:

fireproof rock wool wall panels machine

,

heat preservation mineral wool production line

,

sound insulation rock wool board maker

Mô tả sản phẩm
Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine
This advanced production line combines fireproofing, heat preservation, and sound insulation capabilities for manufacturing high-quality rock wool wall panels with automated efficiency.
Key Specifications
Attribute Value
Product Name Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Voltage 380v Or Customized
Electric Control PLC control
Condition New
Conveying speed 40~120 meters/min
Swing belt width 2800mm
Swing belt motor 4kw (variable frequency motor)
Technical Specifications
  • Product Name: Rockwool Panel Production Line
  • Automatic Grade: Automatic
  • Voltage: 380V
  • Panel Thickness: 30-200mm
  • Felt Size: 1000mm (adjustable)
  • Panel Density: 30-200 Kg/m3
  • Applicable Industries: Manufacturing Plant, Retail, Construction works
  • Finished products: Rock wool board
  • Usage: Building Material Production
System Components
  • Slag and cotton separation system
  • Cotton collection mechanism
  • Screen cleaning device
  • Cotton lifting system
  • Automatic refueling and lubrication system
  • Automatic slag discharge device
The machine features a sturdy steel structure frame with bearing transmission system. The drum includes a mesh plate with installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
